ASUS ROG STRIX 850W PLATINUM Modular 90YE00W8-B0NA00

ROG STRIX 850W Platinum ROG Strix 850W Platinum is a cool and quiet PSU with stable power delivery, engineered for efficiency with GaN MOSFET and intelligent stabilizer in striking style. "GPU-FIRST" voltage sensing with patented-intelligent voltage stabilizer enhances voltage delivery by up to 45% to your graphics card for smoother gameplay and unwavering performance. GaN MOSFET delivers superior power efficiency by up to 30% and a more organized internal layout for cooler operation.

Dual ball fan bearings can last up to twice as long as sleeve bearing designs. Large ROG heatsinks cover critical components, delivering lower temperatures and noise than reference designs. 0dB technology lets you enjoy light gaming in relative silence.

ATX 3.1 compatible: ROG Strix Platinum is compliant with ATX 3.1 standard, ensuring enhanced voltage and current regulation. PCIe 5.1 Ready: ROG Strix Platinum features a native 12V-2x6 connector for next-gen graphics card power. Lambda A Certification Certified low noise levels, below 25 dB.

80 PLUS & Cybenetics Platinum certified: ROG Strix Platinum leverages low-ESR capacitors and premium components for industry-leading power efficiency.? 10-year warranty included. Model ROG STRIX 850W Platinum Intel Form Factor ATX12V PFC Type Active PFC ATX Standard ATX 3.1 80 PLUS Efficiency 80Plus Platinum Protection Features OPP/OVP/UVP/SCP/OCP/OTP Hazardous Materials ROHS AC Input Range 100-240Vac DC Output Voltage +3.3V +5V +12V -12V +5Vsb Maximum Load 25A 25A 70.8A 0.3A 3A Combined Load 130W 130W 850W 3.6W 15W Total Output 850W Cable Connectors MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 (both PSU & component side) PCI-E 6+2-pin x 3 SATA x 6 PERIPHERAL x 3 Package Contents Power Cord x 1 Motherboard Power Cable x 1 (610mm) CPU Cable x 2 (1000mm) PCI-E Gen 5.1 (16-pin-to-16-pin) Cable x 1 (750mm) PCI-E (8-pin-to-6+2pin) Cable x 3 (750mm) SATA 1-to-3 Cable x 2 (400+120+120mm) Peripheral 1-to-3 Cabel x 1 (400+150+150mm) ROG Strix DIY sticker x 1 User Manual x 1 Dimensions 160 x 150 x 86 mm Weight 1.78 kg (single PSU) Cybenetics Noise Level Certification A AURA SYNC No MTBF >120,000 hrs @ 25°C 0dB Fan Button Yes.

When the Button is ON, the fan will only spin up when the system reaches a certain load. When the Button is OFF, the fan will continuously spin at all load levels.
